Description
Baumer R02 RTD is a compact, mineral-insulated, stainless-steel temperature sensor designed for high-response and sanitary applications. Its polished wetted parts, Tri-Clamp options, and Class A platinum sensing element make it ideal for dairy, beverage, pharma, clean steam, sterile loops, and hygienic CIP/SIP lines. R02 delivers stable accuracy under washdown, vibration, thermal shock, and SIP sterilization cycles with long-term calibration integrity.
Baumer R02 — Key Technical Data & Selection Parameters
| Parameter | Specification / Details |
| Sensor Type | Pt100 / Pt1000 IEC 60751 Class A / 1/3 DIN |
| Measurement Range | –50 °C to +250 °C continuous (SIP-rated to +150 °C / short peak +160 °C) |
| Accuracy | Class A: ±(0.15 + 0.002×t) |
| Construction | Mineral-insulated, welded sheath & sanitary stem |
| Process Connection | Tri-Clamp (TC), Dairy SMS, ISO hygienic clamp |
| Immersion Length | 50 mm … 300 mm (customizable for vessels & pipelines) |
| Sheath Material | SS316L (electropolished for hygienic duty) |
| Ingress Protection | IP67 / IP69K for washdown zones |
| Mounting | Clamp-in for pipelines, fermenters, pasteurizers & SIP loops |
| Output | RTD raw element / transmitter-integrated (4–20 mA available) |
| Cable Options | Silicone, PTFE, food-grade cable, hygienic gland |
| Cleanability Standard | EHEDG / FDA compliant surfaces |
| Typical Conditions | CIP (90–98°C), SIP (121–135°C steam cycles) |
| Response Time | Ultra-fast t50 < 2 s / t90 < 5 s (due to MI construction) |
