Description
U500 series ultrasonic proximity sensors are designed for long-range, high-stability object and level detection using ultrasonic sound waves. They reliably detect solid, liquid, powder, and transparent objects independent of color, surface texture, or transparency. With extended sensing distance and strong noise immunity, U500 sensors are ideal for tank level measurement, distance monitoring, bulk material handling, and presence detection in harsh industrial environments such as dust, steam, and humidity.
🔧 U500 Series — Key Technical Data & Selection Parameters
| Parameter | Specification / Details |
| Sensing Principle | Ultrasonic (echo-based sound wave measurement) |
| Detectable Objects | Solids, liquids, transparent materials, bulk solids |
| Sensing Distance | Up to ~5 m (model dependent) |
| Blind Zone | Optimized short blind zone for near detection |
| Output Type | PNP / NPN, NO / NC |
| Output Options | Switching output / Analog (0–10 V, 4–20 mA – model dependent) |
| Supply Voltage | 10…30 V DC |
| Response Time | Designed for stable long-distance measurement |
| Housing Design | Rugged rectangular industrial housing |
| Protection Rating | IP67 |
| Operating Temperature | –25 °C to +60 °C |
| Electrical Connection | Cable or M12 connector |
| Typical Applications | Tank level measurement, bulk storage, distance sensing |
