What This Data Means — Quick Client Selection

  • Hygienic & CIP/SIP ready: Fully welded stainless steel diaphragm ensures zero contamination risk in food, beverage, and pharma lines.
  • High-precision measurement: ±0.25% FS accuracy supports precise dosing, batching, and process control.
  • Robust in tough environments: Resistant to vibration, EMI/RFI noise, and aggressive cleaning chemicals.
  • Flexible process integration: Tri-clamp, SMS, IDF, and threaded connections fit standard sanitary pipelines.
  • Hazardous area ready (optional): ATEX certified versions suitable for flammable or sterile environments.
  • Durable & leak-free: Welded capsule design prevents leaks, ensuring safety for high-purity liquids.
Category: Tag: Brand:

Description

Baumer Clever Level PFMN is a premium, hygienic, and precision-class pressure transmitter designed for demanding sanitary processes. Engineered for long-term stability, high EMI protection, and compatibility with aggressive cleaning agents, it is widely used in dairy, beverage, pharmaceutical, biotech, and food processing plants.

 Baumer Clever Level PFMN — Key Technical Data & Selection Parameters

Parameter Specification / Details
Measuring Range 0…0.1 bar to 0…40 bar (custom ranges available)
Accuracy ±0.25% FS (optional ±0.1% FS)
Output Signal Options 4–20 mA, 0–10 V, HART, IO-Link
Sensor Technology Stainless steel hygienic diaphragm, fully welded, no O-ring
Media Compatibility Water, dairy, beverages, pharma solutions, CIP/SIP media
Process Connection Tri-Clamp (DIN 32676), SMS, IDF, threaded G½ / ¼ NPT
Response Time < 5 ms
Overpressure Strength 2× FS
Ingress Protection IP65 / IP67 / IP69K
Electrical Connections M12x1, DIN connector, cable outlet
Temperature Rating (Media) –10 °C to +120 °C (CIP/SIP compatible)
Approvals EHEDG, 3A, FDA, CE, optional ATEX
EMI / RFI Immunity Industrial class shielding against VFD & motor noise
Application Class Hygienic, high-precision process measurement
